Mill-DW
5-Axis Wet & Dry Milling Machine
Best Choice for a Lab – All in One
| Number of axes | 5 | |
| Processing method | Dry&Wet Milling | |
| Processing denture type | Single crown,bridge,veneer,inlay,abutment,screw-retained crown, screw-retained bridge, etc. | |
| Millable material | Zirconia,PMMA,Wax,Glass Ceramic,Titanium Abutment,Titanium Plate,etc. | |
| Processing material thickness | 10-25mm | |
| Positioning accuracy/repeat positioning accuracy | 0.01mm/0.005mm | |
| Repeatable zero return accuracy | 0.01mm | |
| Calibration accuracy range | ±0.05mm | |
| Calibration cycle | Recommended once a week | |
| Maximum feed speed/maximum idling speed | 5000/10000 mm/min | |
| Linear drive system | Linear guides and lead screws | |
| Rotary drive system | High precision harmonic reducer | |
| Control System | Embedded multi-axis CNC system + servo motor | |
| Machine size | 680×940×1050mm | |
| Machine weight | 150kg | |
| Automatic tool change quantity | 27 | |
| Water tank capacity | 10L | |
